Name: M30-TP SERIES VARIOUS CONSTANT VOLTAGE CONSTANT CURRENT ADJUSTABLE DC POWER SUPPLY
SKU: 1496
Availability: BackOrder

M30-TP SERIES VARIOUS CONSTANT VOLTAGE CONSTANT CURRENT ADJUSTABLE DC POWER SUPPLY

Price range: 278.00€ through 342.00€

Constant voltage and constant current adjustable DC power supply.

Model

Ask about this product

Categories: ADJUSTABLE DC POWER SUPPLIESSKU: N/A

Features:

Output off function
Constant voltage and constant current
Aluminium alloy panel
Series and parallel tracking function (M30-TP Series)

Specifications

Line regulation	CV1x10^-4+3mV	CC2x10^-3+3mA	Fixed output 10mV
Load regulation	CV1X10^-4+4mV	CC2X10^-3+5mA	Fixed output 10mV
Ripple & noise	CV1mVrms	CC3mA rms	Fixed output 10mV
Fixed Output accuracy	2.5%
Display accuracy	Voltmeter±(0.2%Rdg+2digits) Ampmeter±(1.0%Rdg+2digits)
Input voltage	110~127VAC±10%, 220~240VAC±10% Switchable

Model

Voltage

Current

Dimensions(LxWxD)

Weight (kg)

M30-TP202E

0~20Vx2

5V

0~2Ax2

2A

260x160x340mm

10

M30-TP303E

0~30Vx2

5V

0~3Ax2

3V

260x160x340mm

10

M30-TP305E

0~30Vx2

5V

0~5Ax2

3V

260x160x340mm

10

Catalog Card

Download
