| Specifications
.AC thermal-magnetic circuit breaker: 4P/16A/400V/30mA
.Three-phase AC output: 400V/10A+N and PE
.AC outlet: 230V/10A (2 universal single-phase sockets)
.Power supply: 3×400VAC/N/PE/50Hz (or other voltages upon request)
.Dimensions(W×H×D): 400×170×200mm
.Weight: 5kg
TB612
Specifications
.AC thermal-magnetic circuit breaker: 4P/16A/400V/30mA
.AC output:
1. Three-phase AC output: 400V/10A+N and PE
2. AC outlet: 230V/10A (2 universal single-phase sockets)
.DC output: 24V/4A
.Power supply: 3×400VAC/N/PE/50Hz (or other voltages upon request)
.Dimensions(W×H×D): 400×160×200mm
.Weight: 6kg
TB614
Specifications
.AC thermal-magnetic circuit breaker: 4P/16A/400V/30mA
.AC output:
1. Three-phase AC output: 400V/3A+N and PE
2. AC outlet: 230V/4A (2 universal single-phase sockets)
.DC output: 24V/4A
.Power supply: 3×400VAC/N/PE/50Hz (or other voltages upon request)
.Dimensions(W×H×D): 450×200×280mm
.Weight: 16kg
TB616
Specifications
.AC thermal-magnetic circuit breaker: 4P/16A/400V/30mA
.AC output:
1. Three-phase AC output: 400V/10A+N and PE
2. AC outlet: 230V/10A (2 universal single-phase sockets)
3. AC output:110V/10A
4. AC output: 6V/5A
.DC output: 24V/10A
.Power supply: 3×400VAC/N/PE/50Hz (or other voltages upon request)
.Dimensions(W×H×D): 400×160×200mm
.Weight: 9kg |
