TM801 MICROPROCESSOR CONTROLLED TIMER
€430.00 (€528.90 Tax Included)
Microprocessor controlled LCD display universal counter.
Out of stock
Categories: SOLENOIDS & TESLAMETERS & TIMERSSKU: 117876
Features:
- Multiple function
- Microprocessor controlled
- Hand hold and rechargeable battery operation
Introduction
This microprocessor controlled LCD display universal counter can be used for measurement of time intervals, simple pendulum periods, velocity, acceleration, revolutions per second, frequency, pulses etc. It measures time intervals from 0.1 millisecond and frequencies to 20 KHz. The counter is provided with a five-digit LCD display, and a compact case making the apparatus highly suitable for student lab exercises. RJ45 inputs are provided for connection of photogate. Memory is provided for storing measured values.
Catalog Number | 117876 |
---|
Specifications
Technical Data | 5 digits LCD | |
Display | 5 digits LCD | |
Input | RJ45 | |
Start / Stop | from 0.01 s to 12000 s, resolution 0.01s/1s | |
Collision | A and B passage time from 0.1ms to 19999s, resolution 0.1ms | |
Acceleration | passage time and A to B time from 0.1ms to19999s, resolution 0.1ms | |
Period | from 0.1ms to 19999s, resolution 0.1ms | |
Frequency / resolution | from 0.1 Hz to 19999Hz / 0.1 Hz | |
Counter | from 1 count to 19999 counts | |
Memory storage | 10 values | |
Rechargeable battery | 9V/1800mAh | |
Accessory | photogate P416001, RJ45 cable, Power adapter | |
Dimensions | 165 x 95 x 45 mm (timer), 300 x 206 x 60 mm (box) | |
Weight | 1.0 kg (with box) |
Related products

DWB-01 WHEATSTONE BRIDGE WIDE RANGE RESISTANCE BRIDGE
€288.00 (€354.24 Tax Included)
Out of stock

RXG250 SERIES SOLENOID VARIOUS TERMINAL SOLENOID
€168.00 (€206.64 Tax Included)
Out of stock


EH818 HOUSE ELECTRICAL SIMULATION TRAINING SYSTEM
€3,616.00 (€4,447.68 Tax Included)

DBL-06 HIGH PRECISION INDUCTOR BOX DECADE BOX
€372.00 (€457.56 Tax Included)
Out of stock

RXI-1 ADJUSTABLE INDUCTOR VARIABLE INDUCTOR
€336.00 (€413.28 Tax Included)
Out of stock

F3-718 WIND POWER GENERATION
€112.00 (€137.76 Tax Included)

BXL-07 INDUCTOR BOX DECADE BOX
€208.00 (€255.84 Tax Included)

BXR SERIES RESISTOR BOX, DECADE BOX
€74.00 – €124.00
Out of stock


ELECTRON DEFLECTION TUBE SYSTEM
€1,190.00 – €1,576.00


ACL-7000 ANALOGUE TRAINING SYSTEM WITH EXPERIMENTAL BOARD
